Factory Promotional High Quality Most Advanced Electric Single Channel Syringe Pump with Drug Library

Factory Promotional High Quality Most Advanced Electric Single Channel Syringe Pump with Drug Library

Short Description:

Features :

1.Large LCD display

2. Wide range of flow rate from 0.01~9999.99 ml/h ;(in 0.01 ml increments)

3.Automatic KVO with On/Off Function

4.Dynamic pressure monitoring.

5. 8 working modes , 12 levels occlusion sensitivity.

6. workable with docking station .

7.Automatic multi-channel relay.

8. Multiple data transmission


Product Detail

Product Tags

We’ve lots of great employees associates excellent at promoting, QC, and working with types of troublesome problem from the manufacturing process for Factory Promotional High Quality Most Advanced Electric Single Channel Syringe Pump with Drug Library, How about to start your great enterprise with our corporation? We’ve been prepared, qualified and fulfilled with pride. Let’s start our new business with new wave.
We’ve lots of great employees associates excellent at promoting, QC, and working with types of troublesome problem from the manufacturing process for China syringe Pump, We welcome you to visit our company, factory and our showroom displayed various solutions that will meet your expectation, meanwhile, it is convenient to visit our website, our sales staff will try their efforts to offer you the best service. If you require more information, make sure you do not hesitate to contact us by E-mail or telephone.

Syringe Pump KL-6061N

Specifications

Syringe Size 5,10, 20, 30, 50/60 ml
Applicable Syringe Compatible with syringe of any standard
Flow Rate Syringe 5 ml: 0.1-100 ml/h

Syringe 10 ml: 0.1-300 ml/h

Syringe 20 ml: 0.1-600 ml/h

Syringe 30 ml: 0.1-800 ml/h

Syringe 50/60 ml: 0.1-1500 ml/h

0.1-99.99 mL/h, in 0.01 ml/h increments

100-999.9 ml/h in 0.1 ml/h increments

1000-1500 ml/h in 1 ml/h increments

Flow Rate Accuracy ±2%
VTBI 0.10mL~99999.99mL (Minimum in 0.01 ml/h increments)
Accuracy ±2%
Time 00:00:01~99:59:59(h:m:s)  (Minimum in 1s increments)
Flow Rate  ( Body weight ) 0.01~9999.99 ml/h ;(in 0.01 ml increments)

unit: ng/kg/min、ng/kg/h、ug/kg/min、ug/kg/h、mg/kg/min、mg/kg/h、IU/kg/min、IU/kg/h、EU/kg/min、EU/kg/h

Bolus Rate Syringe 5 ml: 50mL/h-100.0 mL/h

Syringe 10 ml: 50mL/h-300.0 mL/h

Syringe 20 ml: 50mL/h-600.0 mL/h

Syringe 30 ml: 50mL/h-800.0 mL/h

Syringe 50/60 ml: 50mL/h-1500.0 mL/h

50-99.99 mL/h, in 0.01 ml/h increments

100-999.9 ml/h in 0.1 ml/h increments

1000-1500 ml/h in 1 ml/h increments

Accuray: ±2%

Bolus Volume Syringe 5 ml: 0.1mL-5.0 mL

Syringe 10 ml: 0.1mL-10.0 mL

Syringe 20 ml: 0.1mL-20.0 mL

Syringe 30 ml: 0.1mL-30.0 mL

Syringe 50/60 ml: 0.1mL-50.0 /60.0mL

Accuracy: ±2% or ±0.2mL

Bolus , Purge Syringe 5mL :50mL/h -100.0 mL/h

Syringe 10mL:50mL/h -300.0 mL/h

Syringe 20mL:50 mL/h -600.0 mL/h

Syringe 30mL:50 mL/h -800.0 mL/h

Syringe 50mL:50 mL/h -1500.0 mL/h

(Minimum in 1mL/h increments)

Accuracy: ±2%

Occlusion Sensitivity 20kPa-130kPa, adjustable (in 10 kPa increments)

Accuracy: ±15 kPa or±15%

KVO Rate 1).Automatic KVO On/Off Function

2).Automatic KVO is turned off : KVO Rate : 0.1~10.0 mL/h adjustable,(Minimum in 0.1mL/h increments).

When flow rate>KVO rate , it runs in KVO rate.

When flow rate <KVO rate , it alarms and runs in flow rate.

3) Automatic KVO is turned on:it adjusts the flow rate automatically.

When flow rate<10mL/h, KVO rate =1mL/h

When flow rate >10 mL/h, KVO=3 mL/h.

Accuracy: ±2%

Basic function Dynamic pressure monitoring, Anti-Bolus, Key Locker, Standby, Historical memory, Drug library.
Alarms Occlusion, syringe drop off, door open, near end , end program, low battery, end battery, motor malfunction, system malfunction, standby alarm, syringe installation error
Infusion Mode Rate mode, Time mode, Body weight, Sequence Mode、Dose Mode、Ramp Up/Down Mode、Micro-Infu Mode
Additional Features Self-checking, System Memory, Wireless (optional), Cascade, Battery Missing Prompt, AC Power Off Prompt.
Air-in-line Detection Ultrasonic detector
Power Supply, AC AC100V~240V 50/60Hz, 35 VA
Battery 14.4 V, 2200mAh ,Lithium, rechargeable
Weight of Battery 210g
Battery Life 10 hours at 5 ml/h
Working Temperature 5℃~40℃
Relative Humidity 15%~80%
Atmospheric Pressure 86KPa~106KPa
Size 290×84×175mm
Weight <2.5 kg
Safety Classification Class ⅠI, type CF. IPX3

CE certificate_00
ISO 13485(英文)_00
CE certificate_01
ISO 13485(英文)_01

FAQ:

Q:what’s the MOQ for this model ?

A: 1 unit.

Q: Is the OEM acceptable ? and what is the MOQ for OEM ?

A: Yes , We can do OEM based on 30 units .

Q: Are you the manufacture of this product.

A: Yes, since 1994

Q: Do you have CE and ISO certificates?

A: Yes . all our products are CE and ISO certified

Q: What is the warranty ?

A: We give two years warranty.

Q: Is this model workable with Docking station?

A: Yes
